SMT-3101 Insulin Syringe Barrel Needle Assembly Machine
(Remarks: It need to working with SMT-3008 to complete the full assembly of insulin syringe)
Brief Introduction
This machine is used to assemble and adhere insulin syringe barrel, cannula, and head cap of insulin syringe needle, including coating oil on the cannula. The device adopts the Keyence programming control system, and the panel is easy to operate with the touch screen.
The servomotor coating mechanism is smooth and uniform. The detection system adopts the Keyence CCD image system from Japan, with high speed at 45 pcs in one second for detecting unqualified needle , and the pneumatic configuration adopts imported components. It is fully automatic which can greatly reduce the labor intensity of operators.
Product parameters
Capacity | 13000 pcs /hour |
Operation of worker | 2-3 operators |
Gas consumption（60m³/h） | 50 cubic per hour |
Air Rating | ＞0.6 Mpa |
Power supply | 6KW |
Occupied area | 7*2.5 meters |
Weight | 6000Kg |
